MOSA GE165 FXC

Name: MOSA GE165 FXC
Brand: MOSA
SKU: CH0J5056
Price: 36678.86 EUR
Availability: InStock

Reference CH0J5056

NOMINAL OUTPUT POWER
Three-phase Stand-by power: 165 kVA (132 kW) / 400V / 238.2A
Three-phase PRP power: 150 kVA (120 kW) / 400V / 216.5 A
Three-phase COP power: 122 kVA (97.6 kW) / 400V / 176.3 A
Frequency: 50 Hz

GENERAL SPECIFICATIONS
Tank capacity: 230 l.
Retention time (75% PRP): 9 h
Measured acoustic power LwA: 94.6 dB(A) (69. 6 dB(A) @ 7m)
Guaranteed Acoustic Power LwA: 96 dB(A) (71 dB(A) @ 7m)
Width: 3400 mm
Length: 1200 mm
Height: 1800 mm
Dry Weight: 2160 kg

List price

71,211.40 € tax incl.

58,370.00 € tax excl.

Discounted Price

36,678.86 € tax incl.

30,064.64 € tax excl.

Shipping from 744.20 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference CH0J5056

Data sheet

Phase: Single phase / Three phase
Maximum power three phase (KW): 132
Continuous power three phase (KW): 120
Maximum power three phase (KVA): 165
Continuous power three phase (KVA): 150
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230 / 400
Engine: FPT (IVECO) NEF67 TE1F, 4 stroke common rail, turbo-aftercooler
Emissions Regulations: Stage 3A
Engine rpm (rpm): 1500
Speed governor: Electronic
Starting system: Electric
Engine capacity (cm³): 6
Number cylinders: 6
Oil capacity (L): 17
Cooling: Water
Inyección: Direct
Alternator: Three-phase synchronous self-excited, self-regulated, brushless
Bore x stroke (mm): 104 x 132
Fuel tank capacity (L): 230
Consumption (L/h): 26.5 at 75% of the load
Running time (h): 9 at 75% of the load
Acoustic power: 94 dB(A)
Acoustic pressure: 70 dB(A) at 7 m
Length (mm): 3400
Width (mm): 1200
Height (mm): 1800
Dry weight (Kg): 2160
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: Optional
Voltage regulator: AVR
Engine manufacturer: FPT Iveco

Specific References

Condition New

MOSA GE165 FXC 132KW generating set

MOSA GE165 FXC is a 132 KW three-phase generator with Iveco diesel engine. The MOSA GE165 FXC generator set is equipped with electric start. The alternator of the MOSA GE165 FXC generator set is synchronous, three-phase, self-excited, self-regulated, brushless with class H insulation with AVR voltage regulator. MOSA GE165 FXC is compact and easy to maneuver and transport thanks to its compact size, with a weight of 2160 kg as well as the practical pierceable base. The MOSA generator set with 230 liters fuel tank has a fuel consumption of 34 liters/hour at 75% of the load for an autonomy of more than 9 hours.

MOSA GE165 FXC technical specifications:

ENGINE DATA
Model: FPT (IVECO) N67 TE1F (Stage 3A)
Net standby output: 145 kW (197.2 hp)
Net PRP output: 131.5 kW (178.8 hp)
Net COP output: 105 kW (143 hp)
Cylinders / Displacement: 6/ 6700 cm³ (6.7 lit. )
Bore / Stroke: 104 / 132 (mm)
Compression Ratio: 17.5 : 1
BMEP (Mean Effective Pressure): 1791 kPa - 1629 kPa
RPM Controller: Electronic
110 % (Stand-by Power): 36.5 l/h
100 % PRP: 34 l/h
75 % PRP: 26.5 l/h
50 % PRP: 20 l/h

If you are looking for another product like MOSA GE165 FXC generator set then you can check other land based generator sets in our catalog.

Images and technical data are not binding.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
