Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

26.4

Continuous power three phase (KW)

24

Maximum power three phase (KVA)

33

Continuous power three phase (KVA)

30

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 x 400V 63A 5P CEE - 1 x 230V 16A 3P CEE

Engine

Lombardini LDW2204

Emissions Regulations

Stationary Use

Engine rpm (rpm)

3000

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

2199

Number cylinders

4

Cylinders' position

In line

Cooling

Water

Alternator

Linz, with brushes

Poles

2

Bore x stroke (mm)

88 x 90.4

Fuel tank capacity (L)

50

Consumption (L/h)

8

Running time (h)

6.3

Acoustic pressure

70 dB(A) at 7 m

Length (mm)

1600

Width (mm)

700

Height (mm)

1050

Dry weight (Kg)

500

Silenced

Yes

Super silenced

Yes

ATS Switch device

No

Voltage regulator

Compound

Engine manufacturer

Lombardini
