GENSET MG 23 US-Y - SINGLE-PHASE/THREE-PHASE GENERATOR 22 KVA
Maximum power Three-phase: 22 KVA
Maximum power Three-phase: 17.6 KW
Power continuous use Three-phase: 19.8 KVA
Power continuous use Three-phase: 15.84 KW
Maximum power Single-phase: 7.3 KVA
Maximum power Single-phase: 5.84 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV88 (STAGE V)
Starting: Electric
Consumption: 3.5 Lt/h
Length: 1645 mm
Width: 755 mm
Height: 1212 mm
Weight: 610 Kg
Super silenced
List price
tax incl.
tax excl.
Discounted Price
13,402.92 € tax incl.
10,986.00 € tax excl.
Shipping from 188.00 € to Italy buy it today.
Calculate Shipping Cost
MG 23 US-Y
Data sheet
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 5.84
- Maximum power single phase (KVA)
- 7.3
- Maximum power three phase (KW)
- 17.6
- Continuous power three phase (KW)
- 15.84
- Maximum power three phase (KVA)
- 22
- Continuous power three phase (KVA)
- 19.8
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 16A CEE - 1 x 400V 32A CEE - 3 x 230V 16A CEE
- Engine
- Yanmar 4TNV88, 4 stroke
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Starting system
- Electric
- Engine capacity (cm³)
- 2190
- Number cylinders
- 4
- Cooling
- Water
- Alternator
- Synchronous
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 70
- Consumption (L/h)
- 3.5
- Running time (h)
- 20
- Acoustic power
- 92 dB(A)
- Acoustic pressure
- 67 dB(A) at 7 m
- Length (mm)
- 1645
- Width (mm)
- 755
- Height (mm)
- 1212
- Dry weight (Kg)
- 610
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional
- Voltage regulator
- Compound / AVR (optional)
- Engine manufacturer
- Yanmar
Specific References
New
GENSET MG 23 US-Y
The GENSET MG 23 US-Y is a single-phase/three-phase 22 KVA diesel generator with electric start.
Thanks to its compact size and its very low weight, the GENSET MG 23 US-Y is a light and easy to transport generator.
The GENSET MG 23 US-Y also has a low fuel consumption: only 3.5 Lt/h at 75% of the load.
The GENSET MG 23 US-Y generator set, thanks to the high quality and efficiency of its components, is ideal for various types of work: from small hobby jobs to large construction sites.
Images and technical data are not binding.
