GENSET MG 11.5 DTK - VEHICULAR GENERATOR 10 KVA

GENSET MG 11.5 DTK - VEHICULAR GENERATOR 10 KVA

FUORI PRODUZIONE

Maximum power Three-phase: 10 KVA
Maximum power Three-phase: 8 KW
Maximum power Single-phase: 3.3 KVA
Maximum power Single-phase: 2.64 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Kubota D1105 (STAGE V)
Starting: Electric
Consumption: 2 Lt/h
Length: 1070 mm
Width: 560 mm
Height: 660 mm
Weight: 320 Kg

Payment methods:

Product: GENSET MG 11.5 DTK - VEHICULAR GENERATOR 10 KVA

Start of Rental

End of Rental

Where to collect / receive the Product

Do you need cables?

SÌNO

Additional Tank?

SÌNO

PERSONAL DATA

Name

Surname

Phone

Company

City

State

Postal Code

Country

VAT or CF

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Ask a question

Product: GENSET MG 11.5 DTK - VEHICULAR GENERATOR 10 KVA

Full Name

Company

Phone

City

Country

Postal code

Message

reCAPTCHA

Offer on letterhead

Product: GENSET MG 11.5 DTK - VEHICULAR GENERATOR 10 KVA

Name

Surname

Company

VAT

Phone

City

Country

Postal code

Shipping address

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MG 11.5 DTK

Data sheet

Phase: Single phase / Three phase
Maximum power single phase (KW): 2.64
Maximum power single phase (KVA): 3.3
Maximum power three phase (KW): 8
Maximum power three phase (KVA): 10
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230 / 400
Engine: Kubota D1105
Engine rpm (rpm): 1500
Starting system: Electric
Engine capacity (cm³): 1123
Number cylinders: 3
Cooling: Water
Alternator: Synchronous
Protection degree: IP23
Motor insulation class: H
Consumption (L/h): 2
Acoustic power: 83 dB(A)
Acoustic pressure: 58 dB(A) at 7 m
Length (mm): 1070
Width (mm): 560
Height (mm): 660
Dry weight (Kg): 320
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: No
Voltage regulator: No
Engine manufacturer: Kubota

Specific References

GENSET MG 11.5 DKT

The GENSET MG 11.5 DKT is a 10 KVA single-phase/three-phase diesel vehicular generator set with electric start.
Thanks to its compact size and low weight, the GENSET 11.5 DKT is an easy to install vehicular generator.
The GENSET MG 11.5 DKT also has a low fuel consumption: only 2 Lt/h at 75% of the load.
The GENSET MG 11.5 DKT generator set, thanks to the high quality and efficiency of its components, is ideal to be mounted on a vehicle.

Images and technical data are not binding.
