GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA

MG 5010 DM
      GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA
      GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA
      GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA
      GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA
      GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA

      Control Panel: Included
      Phase type: Single-phase
      Maximum single-phase power: 6.25 KVA / 5 KW
      Motor: Yanmar L 100 V
      Engine speed: 3000 rpm
      Emissions standard: Stage V
      No. Cylinders: 1
      Cooling: Air
      Displacement: 435 cm3
      Power: 8.8 HP (6.5 kWm)
      Starter: Electric
      Fuel: Diesel
      Voltage: 230 V
      Frequency: 50 Hz
      Fuel consumption 75%: 1.5 Lt/h
      Acoustic pressure: 89 (64 dB at 7 m)
      Length: 700 mm
      Width: 535 mm
      Height: 530 mm
      Dry weight: 145 kg

      List price
      13,725.00 € tax incl.
      11,250.00 € tax excl.
      Discounted Price
      8,098.36 € tax incl.
      6,638.00 € tax excl.
      Shipping from 61.00 € to Italy buy it today.
      Calculate Shipping Cost
      Ask a question

      I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

      Offer on letterhead
      GENSET
      MG 5010 DM

      Data sheet

      Phase
      Single phase
      Maximum power single phase (KW)
      5
      Maximum power single phase (KVA)
      6.25
      Fuel
      Diesel
      Frequency (Hz)
      50
      Voltage (V)
      230
      Engine
      Yanmar L100V, 4 stroke
      Emissions Regulations
      Stage 5
      Engine rpm (rpm)
      3000
      Starting system
      Electric
      Engine capacity (cm³)
      435
      Number cylinders
      1
      Cooling
      Air
      Alternator
      Synchronous
      Protection degree
      IP23
      Motor insulation class
      H
      Consumption (L/h)
      1.5 to 70% of the load
      Acoustic power
      89 dB(A)
      Acoustic pressure
      64 dB(A) at 7 m
      Length (mm)
      700
      Width (mm)
      535
      Height (mm)
      530
      Dry weight (Kg)
      145
      Silenced
      Yes
      Super silenced
      Yes
      Product type
      Generator
      ATS Switch device
      No
      Voltage regulator
      No
      Engine manufacturer
      Yanmar

      Specific References

      New

      GENSET MG5010DM STAGEV VEHICLE-MOUNTED GENERATOR 6.25KVA

      The GENSET MG5010DM is the benchmark StageV Vehicle-Mounted Generator for those
      seeking reliability, power, and innovation in the vehicle generator sector. Designed for
      installation on special vehicles such as service trucks, motorhomes, trucks, caravans,
      and Civil Protection rescue vehicles, this GENSET MG5010DM StageV represents a
      complete solution that combines high performance with a compact and
      lightweight construction.

      Main Features of the GENSET MG5010DM StageV:

      Nominal Power: 6.25 KVA
      Engine: Yanmar 3000 RPM, compliant with European StageV standards
      Power Supply Type: Single-phase
      Control System: Remote control panel
      External Muffler: Reduces noise levels

      Performance and Efficiency

      The GENSET MG5010DM StageV is designed to ensure flawless operation in
      any situation. With a power output of 6.25 KVA, it is capable of powering a
      wide range of electrical equipment, ensuring operational continuity.
      The Yanmar engine, known for its reliability, operates at 3000 RPM, meeting strict
      European StageV regulations that guarantee low environmental impact.

      Quietness and Comfort

      A distinctive feature of the GENSET MG5010DM is its extraordinary quietness.
      Thanks to the external muffler, the generator maintains a sound power level of
      just 89 Lwa, making it ideal for contexts where acoustic comfort is essential,
      such as in recreational vehicles and rescue vehicles.

      Ease of Use and Installation

      The GENSET MG5010DM StageV is equipped with a remote control panel that
      facilitates generator management directly from inside the vehicle. The compact
      dimensions of 700 x 535 x 530 mm and the contained weight of 145 kg allow for
      easy installation without compromising the available space on board the vehicle.

      Detailed Technical Specifications of the GENSET MG5010DM:

      Power Supply Type: Single-phase
      Engine: Yanmar, 3000 RPM, Stage V
      Sound Power Level: 89 Lwa
      Weight: 145 kg
      Dimensions (L x W x H): 700 x 535 x 530 mm
      Control System: Remote control panel
      Muffler: External, for noise reduction



      Are you looking for a generator with different technical specifications? HERE to explore the area dedicated to GENSET generators or other specialized brands.

      Images and technical data are not binding.

      * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
