GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA

Name: GENSET MG 5010 DM - VEHICULAR GENERATOR 6.25 KVA
Brand: GENSET
SKU: MG 5010 DM
Price: 8098.36 EUR
Availability: InStock

Reference MG 5010 DM

Control Panel: Included
Phase type: Single-phase
Maximum single-phase power: 6.25 KVA / 5 KW
Motor: Yanmar L 100 V
Engine speed: 3000 rpm
Emissions standard: Stage V
No. Cylinders: 1
Cooling: Air
Displacement: 435 cm3
Power: 8.8 HP (6.5 kWm)
Starter: Electric
Fuel: Diesel
Voltage: 230 V
Frequency: 50 Hz
Fuel consumption 75%: 1.5 Lt/h
Acoustic pressure: 89 (64 dB at 7 m)
Length: 700 mm
Width: 535 mm
Height: 530 mm
Dry weight: 145 kg

List price

13,725.00 € tax incl.

11,250.00 € tax excl.

Discounted Price

8,098.36 € tax incl.

6,638.00 € tax excl.

Shipping from 61.00 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MG 5010 DM

Data sheet

Phase: Single phase
Maximum power single phase (KW): 5
Maximum power single phase (KVA): 6.25
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230
Engine: Yanmar L100V, 4 stroke
Emissions Regulations: Stage 5
Engine rpm (rpm): 3000
Starting system: Electric
Engine capacity (cm³): 435
Number cylinders: 1
Cooling: Air
Alternator: Synchronous
Protection degree: IP23
Motor insulation class: H
Consumption (L/h): 1.5 to 70% of the load
Acoustic power: 89 dB(A)
Acoustic pressure: 64 dB(A) at 7 m
Length (mm): 700
Width (mm): 535
Height (mm): 530
Dry weight (Kg): 145
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: No
Voltage regulator: No
Engine manufacturer: Yanmar

Specific References

Condition New

GENSET MG5010DM STAGEV VEHICLE-MOUNTED GENERATOR 6.25KVA

The GENSET MG5010DM is the benchmark StageV Vehicle-Mounted Generator for those
seeking reliability, power, and innovation in the vehicle generator sector. Designed for
installation on special vehicles such as service trucks, motorhomes, trucks, caravans,
and Civil Protection rescue vehicles, this GENSET MG5010DM StageV represents a
complete solution that combines high performance with a compact and
lightweight construction.

Main Features of the GENSET MG5010DM StageV:

Nominal Power: 6.25 KVA
Engine: Yanmar 3000 RPM, compliant with European StageV standards
Power Supply Type: Single-phase
Control System: Remote control panel
External Muffler: Reduces noise levels

Performance and Efficiency

The GENSET MG5010DM StageV is designed to ensure flawless operation in
any situation. With a power output of 6.25 KVA, it is capable of powering a
wide range of electrical equipment, ensuring operational continuity.
The Yanmar engine, known for its reliability, operates at 3000 RPM, meeting strict
European StageV regulations that guarantee low environmental impact.

Quietness and Comfort

A distinctive feature of the GENSET MG5010DM is its extraordinary quietness.
Thanks to the external muffler, the generator maintains a sound power level of
just 89 Lwa, making it ideal for contexts where acoustic comfort is essential,
such as in recreational vehicles and rescue vehicles.

Ease of Use and Installation

The GENSET MG5010DM StageV is equipped with a remote control panel that
facilitates generator management directly from inside the vehicle. The compact
dimensions of 700 x 535 x 530 mm and the contained weight of 145 kg allow for
easy installation without compromising the available space on board the vehicle.

Detailed Technical Specifications of the GENSET MG5010DM:

Power Supply Type: Single-phase
Engine: Yanmar, 3000 RPM, Stage V
Sound Power Level: 89 Lwa
Weight: 145 kg
Dimensions (L x W x H): 700 x 535 x 530 mm
Control System: Remote control panel
Muffler: External, for noise reduction
