OUT OF PRODUCTION
INPUT
AC charging input voltage: 220-240 VAC AC charging power: X-Stream 900 W Solar input: 300 W, 11-75 Vdc 10A max. Charger input auto: 12 V / 24 Vdc 8 A
OUTPUT
n ° 2 AC Schuko outputs: 1.4 KW continuous, 2.1 KW peak, 220-240 Vca, 50 Hz / 60 Hz Maximum power of the devices...
INPUT
AC charging voltage: 220-240 VAC AC charging X-Stream: 2000 W Solar input: 800 W, 11-100 Vdc 10A Car charger input: 12 V / 24 Vdc 8 A
OUTPUT
n ° 2 AC Schuko outputs: 2,4 KW continuous, 4,6 KW peak, 220-240 Vca, 50 Hz / 60 Hz n ° 2 USB-A outputs: 12 W per port, 5 Vdc, 2.4 A n ° 2 USB-A for fast charging: 18...
Rated power: 160W (± 5W) Efficiency: 21% -22% Connector type: MC4 Open circuit voltage: 21.4V (Vmp 18.2V ) Short circuit current: 9,6A (Imp 8,8A) Cell type: Monocrystalline silicon Operating and storage temperature: -20 ° C to 85 ° C Closed dimensions: 420 x 680 x 24 mm Open dimensions: 1570 x 680 x 24 mm Weight: 7 kg
Rated power: 110W (± 5W) Efficiency: 21% -22% Connector type: MC4 Open circuit voltage: 21.4V (Vmp 18.2V ) Short circuit current: 6.3A (Imp 6.0A) Cell type: Monocrystalline silicon Operating and storage temperature: -20 ° C to 85 ° C Closed dimensions: 420 x 514 x 24 mm Open dimensions: 1580 x 514 x 24 mm Weight: 6 kg
Front rated power: 220W Rear rated power: 155W Efficiency: 22% -23% Connector type: MC4 Open circuit voltage: 21.4 V (Vmp 18.2V) Front short circuit current: 13A (Imp 12A) Rear short circuit current: 8.8A (Imp 8.4A) Cell type: Monocrystalline silicon Operating and storage temperature: -20 ° C to 85 ° C Dimensions: 820 x 1830 x 25...
Rated power: 400W Efficiency: 22.4% Connector type: MC4 Open circuit voltage: 48 V (Vmp 41 V) Short circuit current: 11A ( Imp 9.8A) Cell type: Monocrystalline silicon Operating and storage temperature: -20 ° C to 85 ° C Open dimensions: 1068 x 2390 x 24 mm Weight: 19 kg
INPUT
AC charging voltage: 220-240 VAC AC charging power: 2875 W Solar input: 1600 W, 11-150 Vdc 15A Car charger input: 12 V / 24 Vdc 8 A
OUTPUT
n ° 2 AC Schuko outputs: 3,6 KW continuous, 7,2 KW peak, 220 Vca, 50 Hz Hz n ° 2 USB-A: 12 W per port, 5 Vcc, 2,4 A n ° 2 USB-A for fast charging: 18 W 5 Vcc,...
