CUMMINS ONAN 0541-1275-01 PTO Clutch Assembly 12 V

Reference 0541-1275-01

CUMMINS ONAN 0541-1275-01 PTO Clutch Assembly 12 V.
Suitable for Cummins Onan marine generators 12 VDC MDKBT/U.
Net Available Power at 1500 rpm: 40 HP (29.8 KWm)
Kit Includes: Clutch, instruction sheet, and brackets and hardware.

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference 0541-1275-01

Data sheet

Frequency (Hz): 50 / 60
Voltage (V): 12
Mechanical power (hp): 40
Product type: Gruppo frizione PTO

Specific References

Condition New

CUMMINS ONAN 0541-1275-01 PTO Clutch Assembly 12V

Front power take-off (PTO) clutch with torsional coupling.

Description
PTO flexible coupling electric clutch to direct drive accessories.
SAE ‘B’ spline 13T 16/32 DP, 2 or 4 bolt pump mount.

Benefits
The PTO Clutch Assembly connects to drive accessories such as windlass or hydraulic thrusters.
The net available power varies by model and is limited by the maximum engine horsepower and maximum clutch engagement RPM.

Installation
Gensets without sound shield require belt guard kit.
Gensets with sound shield require “C” front panel.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
