GENMAC G3T TRASH ENGINE DRIVEN PUMP
      GENMAC G3T TRASH ENGINE DRIVEN PUMP
      GENMAC G3T TRASH ENGINE DRIVEN PUMP

      GENMAC G3T TRASH ENGINE DRIVEN PUMP

      Engine: R270
      Type: 4-stroke, air cooling
      Fuel: Gasoline
      Displacement: 270 ml
      Tank capacity: 5.4 liters
      Autonomy: 3.0 hours
      Suction: Ø 80 (3")
      Delivery: Ø 80 (3")
      Suction capacity: 7 m
      Maximum head: 20 m
      Maximum flow rate: 1100 l / min
      Length: 688 mm
      Width: 528 mm
      Height: 582 mm
      Weight: 64 Kg

      Custom Quote
      Product: GENMAC G3T TRASH ENGINE DRIVEN PUMP

      PERSONAL DATA


      Ask a question
      Product: GENMAC G3T TRASH ENGINE DRIVEN PUMP
      Offer on letterhead
      Product: GENMAC G3T TRASH ENGINE DRIVEN PUMP
      GENMAC
      35458

      Data sheet

      Phase
      Single phase
      Fuel
      Gasoline
      Engine
      R270
      Engine capacity (cm³)
      270
      Cooling
      Air
      Pump type
      High flow rate pump
      Fluid type
      Dirty water
      Height of suction (m)
      7
      Maximum output capacity (Lt/min)
      1100
      Inlet diameter thread type (mm/inches)
      80 mm - 3"
      Outlet diameter thread type (mm/inches)
      80 mm - 3"
      Total head (m)
      20
      Fuel tank capacity (L)
      5.4
      Consumption (L/h)
      0.55
      Running time (h)
      3 at 75% of the load
      Length (mm)
      688
      Width (mm)
      528
      Height (mm)
      582
      Dry weight (Kg)
      64
      Silenced
      No
      Super silenced
      No
      Product type
      Pompa

      Specific References

      New

      GENMAC G3T TRASH HIGH MOTORPUMP DIRTY WATER

      The motorpump Genmac G3T TRASH is self-priming gasoline powered with a displacement of 212 ml of power with air cooling suitable for any application for dirty water.

      The self-priming Genmac motorpump Suitable for dirty water and sludge with a
      percentage of solidity up to 50%. Used on construction sites, in emergency
      road repairs, for mud slurry. They could also be used as clean water
      pumps.

      The Genmac G3T TRASH engine has a cast iron cylinder barrel with excellent performance and highly reliable semi-professional quality, easy to start, ensures low noise and vibration with reduced consumption. Thanks to its only 35 kg of weight it is easy to transport wherever it is needed.

      The Genmac self-priming dirty water motorpump has a maximum flow rate of 1100 liters per minute which makes it incredibly efficient due to its small and handy size.

      The Genmac self-priming motorpump is part of a type of hydraulic centrifugal pumps with over-beam installation.

      So, like all such types of machines, it sucks in from a higher level of the liquid to be pumped and therefore needs adequate priming in order to function properly.

      Self-priming is the ability to suck in the air contained in the suction duct during the starting phase of the motorpump.

      Once the motorpump has been installed and before its first start, the body must be filled with water through a special upper door.

      Then the motorpump is put into operation; the rotating movement of the impeller creates a strong turbulence in the liquid contained inside the pump body that generates a depression (up to 0.8 bar) inside the pipe that sucks in the air contained in it.

      MOTORPUMPS TECHNICAL FEATURES FOR GENMAC G3T TRASH

      Engine: R270
      Type: 4-stroke, air cooling
      Fuel: Gasoline
      Displacement: 270 ml
      Tank capacity: 5.4 liters
      Autonomy: 3.0 hours
      Suction: Ø 80 (3")
      Delivery: Ø 80 (3")
      Suction capacity: 7 m
      Maximum head: 20 m
      Maximum flow rate: 1100 l / min
      Length: 688 mm
      Width: 528 mm
      Height: 582 mm
      Weight: 64 Kg

      Are you looking for a product with different characteristics? Here you can findthe full range of Genmac diesel and gasoline motorpumps or other specialized brands.

      Images and technical data of the motorpump for dirty water not binding and may be subject to revision by the supplier
