    TELECO-Connect - WING-LAN11 Omnidirectional Antenna
    TELECO-Connect - WING-LAN11 Omnidirectional Antenna
    TELECO-Connect - WING-LAN11 Omnidirectional Antenna
    TELECO-Connect - WING-LAN11 Omnidirectional Antenna

    TELECO-Connect - WING-LAN11 Omnidirectional Antenna

    TELECO-Connect - WING-LAN11 Omnidirectional Antenna

    Package Contents:

    1 Complete antenna with 5 m coaxial cable for DVBT/T2, 5 m coaxial cable with SMA connector for 2G-3G-4G-5G, and 3 F-connectors
    1 Adjustable gain amplifier with 3 outputs for 3 TVs + 1 output for DAB and FM radio, compatible with 12 and 24 Vdc power supplies.

    Type of orientation: Manual
    Antenna diameter: 380 mm
    Length: 380 mm
    Width: 380 mm
    Height: 165 mm
    Weight: 1.2 kg

    Prezzo
    263.52 € tax incl.
    216.00 € tax excl.
    Shipping Free to Italy buy it today.
    Calculate Shipping Cost
    Custom Quote
    Product: TELECO-Connect - WING-LAN11 Omnidirectional Antenna

    PERSONAL DATA


    Ask a question
    Product: TELECO-Connect - WING-LAN11 Omnidirectional Antenna
    Offer on letterhead
    Product: TELECO-Connect - WING-LAN11 Omnidirectional Antenna
    TELAIR
    20304

    Data sheet

    Diameter (Ø)
    38 cm
    Length (mm)
    380
    Width (mm)
    380
    Height (mm)
    165
    Product type
    Omnidirectional Antenna and Internet
    Antenna orientation
    Manual
    Weight (Kg)
    1.2

    Specific References

    TELECO-CONNECT - WING-LAN11 OMNIDIRECTIONAL ANTENNA

    The TELECO-Connect - WING-LAN11 Omnidirectional Antenna is the perfect solution for those looking for a versatile and powerful device capable of receiving terrestrial digital signals and connecting to the 4G/5G internet network. Designed to meet the needs of motorhomes, caravans, and vehicles in motion, this antenna TELECO - WING-LAN11 features an ultra-aerodynamic shape that allows for easy installation, even on the sleek roofs of modern vehicles.

    The TELECO-Connect - WING-LAN11 Omnidirectional is the ideal choice for those seeking a complete solution for receiving TV signals and internet connectivity. Thanks to its ability to support 2G-5G frequencies and its 3-axis rotation, this antenna offers easy installation, reliable reception, and a stable connection, even in the most remote areas. Perfect for motorhomes and caravans, the TELECO - WING-LAN11 is the essential accessory for an uncompromised travel experience, ensuring continuous entertainment and connectivity.


    Main Features of the TELECO-Connect - WING-LAN11 Omnidirectional Antenna:

    Omnidirectional Antenna for TV and Radio Signals: The TELECO- WING-LAN11 integrates an omnidirectional TV antenna for receiving DVBT/T2 digital terrestrial signals and DAB+ Radio, ensuring excellent quality viewing and listening wherever you are.

    Internet Reception 2G-3G-4G-5G: Equipped with a powerful high-efficiency internet antenna, the TELECO-Connect - WING-LAN11 is compatible with mobile technologies 2G, 3G, 4G, and 5G, providing a stable and fast connection.

    3-Axis Rotation: Thanks to the 3-axis rotation, the antenna TELECO allows for optimal alignment with the vehicle's roof, ensuring excellent reception, even on the aerodynamic roofs of modern motorhomes and caravans.

    Easy Installation: Equipped with a special ergonomic foot, the antenna can be tilted in any direction, making installation extremely easy and fast, even on difficult surfaces.


    Technologies and Frequencies of the TELECO- WING-LAN11:

    Reception Frequencies of the TELECO:

    TV: Channels 5-12 and 21-48 with up to 26 dB gain.

    Internet: 2G-5G frequencies:

    5G: 700 MHz (B28),

    4G LTE: 800 MHz (B20), 900 MHz (B8),

    3G UMTS: 900/1800 MHz,

    GSM: 900/1800 MHz.


    Gain with TELECO - WING-LAN11 Omnidirectional Amplifier:

    TV (channels 5-12): 16 dB,

    TV (channels 21-48): 26 dB,

    Internet (4G/5G): high efficiency for a stable and fast connection.


    Dimensions and Power Supply:

    Diameter: 38 cm, for stable reception and excellent performance even in challenging conditions.

    Height: 16.5 cm, with a compact shape that minimizes air resistance.

    Weight: 1.2 kg, ensuring easy installation and transport.

    Power Supply: Works on both 12 V and 24 V, compatible with most vehicles.


    Package Contents of the TELECO:

    Each TELECO-Connect - WING-LAN11 Omnidirectional kit includes:

    1 Complete antenna with 5 m coaxial cable for DVBT/T2,

    5 m SMA coaxial cable for 2G-3G-4G-5G,

    3 F-connectors for easy installation and connection.

    Adjustable gain amplifier with 3 outputs for 3 TVs and 1 DAB/FM Radio output, operating at 12/24 Vdc for optimal signal.


    The TELECO-Connect - WING-LAN11 Omnidirectional is the antenna that revolutionizes reception and connectivity, bringing the signal wherever you go.

    Looking for a product with different features? HERE you can find the entire range of TELECO and other specialized brands.
    Images and technical data are non-binding and subject to changes by the manufacturer.
