SINCRO R80 LBL Single Phase Synchronous AC Alternator 2.2 kVA Capacitor
      SINCRO R80 LBL Single Phase Synchronous AC Alternator 2.2 kVA Capacitor
      SINCRO R80 LBL Single Phase Synchronous AC Alternator 2.2 kVA Capacitor

      SINCRO R80 LBL Single Phase Synchronous AC Alternator 2.2 kVA Capacitor

      R80 LBL J609 c19

      Phase Type: Single-phase
      Maximum single-phase output: 2.2KW
      Maximum single-phase continuous output: 1.76KW
      Maximum single-phase output: 2.7KVA
      Maximum single-phase continuous output: 2. 2KVA
      Frequency: 50-60 Hz
      Voltage: 230 V
      Protection class: IP23
      Alternator speed: 3000 rpm
      Number of poles: 2
      Weight: 13. 8 Kg
      Width: 171 mm
      Length: 261 mm
      Height: 240 mm
      Brushless
      Voltage regulator: Capacitor
      Type of alternator: constant speed

      List price
      355.02 € tax incl.
      291.00 € tax excl.
      Discounted Price
      234.24 € tax incl.
      192.00 € tax excl.
      Custom Quote

      PERSONAL DATA


      Ask a question

      I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

      Offer on letterhead
      SINCRO
      R80 LBL J609 c19

      Data sheet

      Phase
      Single phase
      Frequency (Hz)
      50
      Voltage (V)
      230
      Engine rpm (rpm)
      3000
      Poles
      2
      Single-phase power (KW)
      2.2
      Single-phase power (KVA)
      2.2
      Efficiency (%)
      73
      Protection degree
      IP23
      Dry weight (Kg)
      14
      Brushes
      No
      Type of alternator
      Constant Speed
      Voltage regulator
      Capacitor

      Specific References

      New

      SINCRO R80 LBL ALTERNATOR 2,7KVA SINGLE-PHASE

      SINCRO R80 LBL singlephase alternator with a power of 2,7KVA, this unit has a Brushless operation equipped with capacitor voltage regulator.

      The SINCRO R80 LBL is foreseen for the operation at frequency 50 or 60 HZ, the possibility to work on these two frequencies makes possible its application for any service voltage increasing its versatility, for the correct operation. For the correct operation it is only necessary to verify that the calibrations are correct for the intended use.

      All components that make up the SINCRO R80 LBL are subjected to a specific coating and/or impregnation process to safeguard the functionality of the generator and to protect the critical peers in various conditions of use.

      For extreme atmospheric conditions models are available that also guarantee the IP23 standard which provides protection against water up to 60° from the vertical. SINCRO R80 LBL is a brushless alternator, this feature combined with the high efficiency of the voltage regulator ensure a low level of interference with radio waves.

      The singlephase alternator is lightweight and small in size, suitable for installation on board of compact and transportable machines, ensuring reliability and high performance.

      Select the alternator that reflects the technical specifications you require, visit our dedicated section to understand how.

      TECHNICAL FEATURES SINCRO R80 LBL

      Phase Type: Single-phase
      Maximum singlephase output: 2,2KW
      Maximum singlephase continuous output: 1,76KW
      Maximum singlephase output: 2,7KVA
      Maximum singlephase continuous output: 2,2KVA
      Frequency: 50-60 Hz
      Voltage: 230 V
      Protection class: IP23
      Alternator speed: 3000 rpm
      Number of poles: 2
      Weight: 13. 8 Kg
      Width: 171 mm
      Length: 261 mm
      Height: 240 mm
      Brushless
      Voltage regulator: Capacitor
      Type of alternator: constant speed

      Looking for a product with different features? Here you can find the entire range SINCRO and other specialized brands.

      Images and technical data are not binding and subject to change by the manufacturer

      * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
      B3/B9 coupling (cone 23, cone 30).
          B3/B9 coupling (cone 23, cone 30).
          0.00 €Price
          SINCRO RC01 panel for R80 models.
              RC01 panel for R80 models. - Cover - Connector with cables - Capacitor
              9.00 €Price
              SINCRO RM01 panel for R80 models.
                  RM01 panel for R80 models. - 1 Schuko - Thermal protection
                  16.00 €Price
                  SINCRO RM02 PANEL FOR R80 MODELS
                      RM02 panel for R80 models. - 2 Schuko - Thermal protection
                      26.00 €Price
