MECC ALTE ES16W-75 SINGLE PHASE ALTERNATOR 2.3 KVA
      MECC ALTE ES16W-75 SINGLE PHASE ALTERNATOR 2.3 KVA
      MECC ALTE ES16W-75 SINGLE PHASE ALTERNATOR 2.3 KVA
      MECC ALTE ES16W-75 SINGLE PHASE ALTERNATOR 2.3 KVA

      MECC ALTE ES16W-75 SINGLE PHASE ALTERNATOR 2.3 KVA

      ES16W-75 J609a c19

      Phase type: Single phase
      Single phase maximum power: 2 KW
      Single phase continuous power: 1.6 KW
      Single phase maximum power: 2.5 KVA
      Single-phase continuous use power: 2.3 KVA
      Frequency: 50 - 60 Hz
      Voltage: 230 V
      Degree of protection: IP21
      Alternator speed: 3000 rpm
      Number of poles: 2
      Sound pressure level: 72 dBA (56 dBA at 7 m)
      Efficiency: 73.7%.
      Weight: 15,6 Kg
      Constant speed alternator
      Voltage regulator: ASR

      List price
      422.12 € tax incl.
      346.00 € tax excl.
      Discounted Price
      272.06 € tax incl.
      223.00 € tax excl.
      Choose the type of coupling :
      Download PDF
      Custom Quote

      PERSONAL DATA


      Ask a question

      I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

      Offer on letterhead
      MECC ALTE
      ES16W-75 J609a c19

      Data sheet

      Phase
      Single phase
      Maximum power single phase (KW)
      2
      Continuous power single phase (KW)
      1.6
      Maximum power single phase (KVA)
      2.5
      Continuous power single phase (KVA)
      2.3
      Frequency (Hz)
      50 / 60
      Voltage (V)
      230
      Engine rpm (rpm)
      3000
      Poles
      2
      Single-phase power (KVA)
      2.7
      Efficiency (%)
      73.7
      Protection degree
      IP21
      Acoustic power
      72 dB(A)
      Acoustic pressure
      56 dB(A) at 7 m
      Brushes
      Yes
      PMG
      No
      Type of alternator
      Constant Speed
      Voltage regulator
      ASR
      Weight (Kg)
      14.3

      Specific References

      New

      MECC ALTE ES16W-75 SINGLEPHASE ALTERNATOR 2.3 KVA

      The alternator singlephase MECC ALTE ES16W-75 with 2 poles is able to deliver a continuous power of 2,3KVA complete with ASR voltage regulator.

      The MECC ALTE ES16W-75 alternators are designed to be exceptionally versatile, they are made to be suitable for all applications where an easy-to-transport power source is needed.

      Mecc Alte portable alternators are available with a wide range of shafts, flanges and fittings. The 2-pole rotors have a damping cage and the stator windings have a reduced pitch to reduce harmonic content.

      The alternator MECC ALTE ES16W-75 single-phase alternators are designed without brushes and offer high operational reliability. As there are no collectors or sliding contacts, minimal maintenance is required. The three phase range is designed with brushes and slip ring and is controlled by the transformer. This allows for high load capacity, ideal for motor starting applications.

      The alternator MECC ALTE ES16W-75 range is single phase AVR controlled, but designed with brushes and slip ring to allow good voltage regulation and better motor starting; power loads other than power factor 1.0, such as modern electronic products or pumps.

      MECC HIGH TECHNICAL CHARACTERISTICS ES16W-75

      Phase type: Single phase
      Singlephase maximum output: 2 KW
      Singlephase continuous output: 1.6 KW
      Singlephase maximum output: 2.5 KVA
      Singlephase continuous output: 2.3 KVA
      Frequency: 50 - 60 Hz
      Voltage: 230 V
      Degree of protection: IP21
      Alternator speed: 3000 rpm
      Number of poles: 2
      Sound pressure level: 72 dBA (56 dBA at 7 m)
      Efficiency: 73.7%.
      Weight: 15,6 Kg
      Constant speed alternator
      Voltage regulator: ASR

      Are you looking for an alternator with different characteristics? Here you can find all MECC ALTE range and other specialized brands

      Images and technical data are not binding and may be subject to manufacturer's revisions.

      * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
